Saucer Drain Cover

Smart drainage management β€” designed to keep roads safe, drains flowing, and cities flood-free.

Drainage Solution

Igloo Saucer
Drain Cover

"Smart Flow. Safe Roads. No Flooding."

Igloo Saucer Drain Covers are precast concrete units specifically designed to cover roadside open drains (U-drains) while allowing maximum water flow-through. The saucer (concave) profile design on the upper surface directs surface water towards the drain openings even when the cover is placed flat β€” preventing road ponding that is a critical issue across Tamil Nadu during the northeast monsoon (October–December). The robust concrete construction handles repeated vehicle overruns without cracking or displacement.

βœ“
Saucer profile directs surface runoff into drain openings
βœ“
Compressive strength β‰₯ 35 MPa β€” handles vehicle loads
βœ“
Anti-slip ribbed top surface for pedestrian safety
βœ“
Standard lengths 600mm, 900mm & 1000mm
βœ“
Suitable for widths 300mm to 600mm U-drains
βœ“
TNUIFSL, municipality & PWD specification compliant
Product Specifications
Standard Length
600 / 900 / 1000mm
Channel Width Fit
300 / 450 / 600mm
Thickness
80 / 100mm
Compressive Strength
β‰₯ 35 MPa
Load Capacity
Up to 12.5T
Water Absorption
≀ 6%
Flood Prevention
The saucer profile ensures all surface water is channeled into the drain opening β€” dramatically reducing road flooding even during peak monsoon rainfall rates above 100mm/hour.
Pedestrian Safety
Anti-slip ribbed surface prevents falls on wet covers. Flush-fit installation eliminates trip hazards that are common with poorly fitted drain covers on Indian footpaths.
Traffic Loadbearing
Designed to withstand repeated overrun by two-wheelers, cars, and light commercial vehicles without cracking, rocking, or displacement β€” common failure modes of thin covers.
Easy Maintenance
Standard dimensions allow single worker removal for drain cleaning without tools. Heavy enough to prevent displacement during flooding yet manageable for routine maintenance.
Road-side Drains
Urban Drainage
Housing Layouts
Industrial Yards
Institutions
Railway Stations
Smart City Projects
Parks & Gardens
Compressive Strength
β‰₯ 35 MPa
Water Absorption
≀ 6%
Load Capacity
Up to 12.5T
Standard Lengths
600 / 900 / 1000mm
Channel Widths
300 / 450 / 600mm
Thickness
80 / 100mm
Surface
Ribbed Anti-Slip
Profile
Concave (Saucer)
Design Life
25+ Years

Ready-Stock & Custom Drain Covers

Ready-to-dispatch stock across all standard sizes. Custom dimensions available for special projects.
